雙頭連接管
PART | TYPE | ￠D | ￠d | L | ******電流 |
00801 | L1.0 | 3.3 | 1.9 | 20 | 19 |
00802 | L1.5 | 4.0 | 2.2 | 20 | 19 |
00803 | L2.5 | 4.5 | 2.9 | 20 | 27 |
00804 | L4.0 | 5.2 | 3.6 | 20 | 37 |
00805 | L6.0 | 6.0 | 4.2 | 20 | 48 |
00806 | L10 | 7.0 | 5.0 | 20 | 62 |
00807 | L16 | 7.8 | 5.8 | 40 | 88 |
00808 | L20 | 8.0 | 6.5 | 40 |
|
00809 | L25 | 9.5 | 7.5 | 45 | 115 |
00810 | L35 | 11.4 | 8.6 | 45 | 160 |
00811 | L50 | 12.6 | 9.6 | 45 | 215 |
00812 | L70 | 15.0 | 12.0 | 50 | 235 |
00813 | L95 | 17.4 | 13.5 | 50 | 255 |
00814 | L120 | 19.8 | 15.0 | 55 | 300 |
00815 | L150 | 21.2 | 16.5 | 60 | 395 |
00816 | L185 | 23.5 | 18.5 | 65 |
|
00817 | L240 | 26.5 | 21.5 | 80 | 470 |
00818 | L300 | 30.0 | 23.5 | 85 | 650 |
00819 | L400 | 36.5 | 28.5 | 90 | 650 |
00820 | L500 | 39.0 | 30.5 | 100 |
|
00821 | L550 | 42.0 | 32.0 | 100 |
|
00822 | L630 | 45.0 | 35.5 | 110 |
PART | TYPE | WIRE RANGE | L | l | ￠D | ￠d | COLOR | ******電流 | CRIMPING | |
AWG/MCM | MM2 | |||||||||
02101 | BF1.25 | 22-16 | 0.25-1.65 | 23.7 | 15 | 4.0 | 1.9 | RED 紅 | 19 | YYT-1 |
02102 | BF2 | 16-14 | 1.04-2.63 | 23.7 | 15 | 4.5 | 2.4 | BLUE 藍(lán) | 27 | |
02103 | BF5.5 | 12-10 | 2.63-6.64 | 25.7 | 15 | 6.8 | 4.0 | YELLOW 黃 | 48 | |
